This boat is owner-constructed and was completed in 2024 after five years of careful and
meticulous work. The boat is a Glen L Marine design and all materials and mechanical
components comply with the recommendations of the designer. The length and beam of
the boat are 19 feet and five and a half feet respectively. The boat has been used
sparingly over the past two years because of drought related water conditions in
Colorado. To date, it has slightly less than 20 hours on the motor.
Construction: The construction method is “cold molding” using marine grade mahogany
plywood over fir frames, keel and motor stringers. The bottom comprises four layers of
?” plywood embedded in epoxy. The bottom is also fiber glassed and painted. The
sides and deck are two layers of plywood embedded in epoxy with 5/32” solid
mahogany veneer planks. Sides and deck are also fiber-glassed. Splash rails and rub
rails are laminated mahogany formed to the contours of the hull and deck. The fiberglassing
of the deck, sides and transom allow the full color and grain of the mahogany to
show completely. The stem and bow area are protected by multiple layers of fiberglass
for added protection. These surfaces are painted.
Other Features: To enhance the simplicity of maintenance, several nonstandard
improvements were implemented. The interior of the cockpit can be quickly
disassembled to access wiring, cables and the inner hull. The beam between the dual
cockpits can also be removed quickly to move freely around the inside of the boat, for
example, while cleaning or fishing. There is a small hatch behind the engine bay to access the rudder assembly and drain plugs. There is also a removable false beam
forward of the engine bay to allow access to the front of the engine for maintenance
purposes.
Mechanical and Electrical: The boat is powered by a new Mercruiser 3.0 liter motor
and a ZF45A transmission. The motor is rated at 135 horsepower. The motor and transmission were purchased in 2019 and installed in 2020. The boat was not completed until 2023 and launched in 2024. The throttle and
transmission controller is also a Mercruiser component. The fuel tank holds 26 gallons
of gasoline. All gauges and wiring harnesses are new and were provided by the supplier
of the motor and transmission. All Coast Guard required equipment has been installed;
eg, bilge pump, engine bay exhaust fan, navigation lights, fire extinquisher, etc.
